New energy vehicle charging gun test

On September 7, 2023, the new national standard for new energy vehicle charging guns GB/T 20234.1-2023 "Connection Devices for Conductive Charging of Electric Vehicles Part 1: General Requirements" was officially released and came into effect. Compared with GB/T 20234.1-2015, GB/T 20234.1-2023 puts forward more stringent requirements for charging guns in terms of safety, durability and reliability.

New energy vehicle charging gun test

Common charging gun test standards
GB/T 20234.1 "Connecting devices for conductive charging of electric vehicles - Part 1: General requirements"
GB/T 20234.2 "Connecting devices for conductive charging of electric vehicles - Part 2: AC charging interface"
GB/T 20234.3 "Connecting devices for conductive charging of electric vehicles - Part 3: DC charging interface"
GB/T 18487.1 "Electric vehicle conductive charging system Part 1: General requirements"
IEC 62196-1 "Plugs, sockets, vehicle connectors and vehicle jacks. Conductive charging of electric vehicles. Part 1: General requirements"
IEC 61851-1 "Electric vehicle conductive charging system Part 1: General requirements"
UL 2251 "Electric vehicle plugs, sockets, vehicle connectors"

Charging gun test project
For standards such as GB/T 20234.1-2023 and IEC 62196-1:2022, LCS Testing has introduced a full set of charging gun testing equipment to meet the testing and certification requirements of AC charging guns. The core testing equipment includes: vehicle rolling testing machine, charging interface cable bending testing machine, charging gun mechanical strength testing equipment, charging gun plug-in life testing machine, resistive-inductive load cabinet, high-power power supply system, etc.

lcs charging gun laboratory

common enquiries
Appearance and structural requirements
Size and type requirements of charging interface
Screws, current-carrying parts and connection requirements
Terminal and Heading Requirements
Requirements for protection against electric shock

Electrical properties
Grounding measures
Breaking capacity
surface temperature
Temperature monitoring requirements
Insulation resistance and dielectric strength

Durability test
Locking device durability test
Normal operation endurance test (service life)
Contact durability test
Switching element durability test

environmental reliability
High and low temperature tolerance
alternating heat and humidity
temperature shock
IP protection level

mechanical reliability
Vehicle crush test
Charging cable connection strength (tension and twist test)
Mechanical strength (pendulum impact, bending, etc.)
Vibration/Shock Test
Offset operation test

Material testing
Aging resistance of rubber and thermoplastic materials
Corrosion resistance and rust prevention of shell
Heat resistance, flame resistance and tracking resistance test
Testing of prohibited and restricted substances (ELV, ROHS, SOC, etc.)
