Automotive ELV
What is ELV:

ELV (End-of-Life Vehicle) is the end-of-life vehicle directive
NELV (Nature ELV) naturally scrapped vehicle
PELV (Premature ELV) traffic accident scrapped vehicle

Legal basis:

Legal basis: The Ministry of Industry and Information Technology of the People's Republic of China announced Order No. 38 of 2015 to protect the ecological environment, improve the efficiency of comprehensive utilization of resources, promote the transformation of the automobile industry's production methods and consumption patterns into green, low-carbon, clean and safe, and improve the international competitiveness of products. , the Ministry of Industry and Information Technology formulated the "Management Requirements for Hazardous Substances and Recycling Rates of Automobiles". The calculation methods for the use of hazardous substances and recyclability of new products should comply with the requirements of the national standards "Requirements for Prohibited Substances in Automobiles" and "Calculation Methods for Reusability and Recyclability of Road Vehicles" respectively, and be included in the "Vehicle Manufacturers and Products announcement". Implementation will be delayed by 24 months for production vehicles. GB/T 30512-2014 (Requirements for prohibited substances in automobiles) Released on February 19, 2014 (General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China, China National Standardization Administration) Officially implemented on June 1, 2014

Introduction to ELV testing

Automobile banned substance detection | Main test products and projects:

•Main testing products: complete vehicles, auto parts and materials

​​​​​​​ •Detectable items:

​​​​​​​

serial number

Test items

According to the standard

Complete vehicle

Vehicle Disassembly Manual, Prohibited and Restricted Substances, RRR

National standard

Parts and Materials

1

Lead (Pb), cadmium (Cd), mercury (Hg)

GB/T 30512-2014, OEM standards

Hexavalent chromium (Cr6+)

Polybrominated biphenyls (PBB)

Polybrominated diphenyl ethers (PBBDE)

2

Asbestos

OEM standards

3

Phthalates (PHT)

OEM standards

4

Polycyclic Aromatic Hydrocarbons (PAHs)

OEM standards

​​​​​​​ Automobile banned substance detection | Vehicle dismantling:

​​​​​​​

​​​​​​​ Automobile banned substance detection | Vehicle dismantling:

​​​​​​​ The Ministry of Industry and Information Technology has made a clear interpretation of supplier responsibilities in the "Management Requirements": "Automotive parts and material suppliers at all levels should truthfully provide product materials and hazardous substance use information to benefit automobiles. Tracking and analysis of hazardous substances and recyclability rates of automobiles by manufacturing enterprises."

​​​​​​​

From January 1, 2016, the use of passenger vehicles (M1) with no more than nine seats (M1) harmful substances and recyclable utilization rates are implemented. At the same time, automobile production enterprises should Within 6 months of obtaining the "Announcement" for new products, the "Automobile Dismantling Guidance Manual" will be provided to recycling and dismantling enterprises through appropriate channels and methods.

​​​​​​​

​​​​​​​

​​​​​​​ Automobile banned substance detection | Main equipment:

​​​​​​​ Ultraviolet-Visible Spectrophotometer (UV-Vis)​​​​​​​

​​​​​​​ Equipment model: 7230G (Sunny Hengping)

​​​​​​​​Test project: Hexavalent chromium content test

​​​​​​​ Applicable standards: IEC62321-7-1/ IEC62321-7-2/ GB/T26125-2011 /GB/T 30512-2014/ QC/T 942-2013

​​​​​​​

​​​​​​​ Automatic robotic arm&XRF

​​​​​​​ Equipment model: Huixiang/Huawei/Tianrui/Shimadzu

​​​​​​​ Operation cycle: 7*24 hours uninterrupted

​​​​​​​​Test project: Lead/cadmium/mercury/chromium/bromine content screening test

​​​​​​​ Applicable standards: IEC62321/ GB/T26125-2011 /GB/T 30512-2014/ QC/T 941~944

​​​​​​​

​​​​​​​ Gas Chromatography Mass Spectrometer (GC-MS)

​​​​​​​ Equipment model: ICP5110 (Agilent)

​​​​​​​Test project: Lead/cadmium/mercury content test

​​​​​​​ Applicable standards: IEC62321/GB/T26125-2011/GB/T 30512-2014/ QC/T 941, 3-2013

​​​​​​​

​​​​​​​Polarizing Microscope

Equipment model: DM 2700 P (Leica)

Test project: Qualitative testing of asbestos

Applicable standards: GB/T 23263-2009/IS0 22262-1:2012

X-Ray Diffractometer

Equipment model: TD3500

Test project: Qualitative testing of asbestos

Applicable standards: GB/T 23263-2009/IS0 22262-1:2012
