IP XX Reliability Test Electrical Appliances Water-Proof Prevent Intrusion Of Foreign Objects ETL/UL/TUV/MET

IP XX Reliability Test Electrical Appliances Water-Proof Prevent Intrusion Of Foreign Objects ETL/UL/TUV/MET

Brand Name: LCS
Model Number: Optional
MOQ: 1 pcs
Price: 100 USD
Packaging Details: Electronic version
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram,Wechat. Alipay
Detail Information
Place of Origin:
CN
Certification:
IPXX
Level 0:
No Dust Protection At All
Level 1:
Can Protect Against Foreign Objects With A Diameter Greater Than 50mm Falling Into The Equipment
Level 2:
Can Protect Against Foreign Objects With A Diameter Greater Than 12.5mm Falling Into The Equipment
Level 3:
Can Protect Against Foreign Objects With A Diameter Greater Than 2.5mm Falling Into The Equipment
Level 4:
Can Protect Against Foreign Objects With A Diameter Greater Than 1.00mm Falling Into The Equipment
Level 5:
It Cannot Completely Prevent Dust From Entering, But The Amount Of Dust That Enters Must Not Affect The Normal Operation Of The Equipment And Must Not Affect Safety
Level 6:
Completely Dustproof
Supply Ability:
50000 pcs per year
Product Description

INGRESS PROTECTION THE LEVEL OF ELECTRICAL APPLIANCES THAT ARE DUST-PROOF AND PREVENT THE INTRUSION OF FOREIGN OBJECTS

The protection level is usually expressed by IP followed by two numbers. The numbers are used to clarify the level of protection.



The first digit indicates the device's resistance to fine dust, or the extent to which people are protected from hazards in a sealed environment. Represents the level of preventing the entry of solid foreign objects, the highest level is 6;


The second digit indicates how waterproof the device is. Represents the level of water intrusion prevention, the highest level is 8.

IEC/EN60529 dustproof is divided into 7 levels (level 0 ~ level 6), dustproof level (e.g. IP5X-dustproof level 5)
Level 0: No dust protection at all
Level 1: Can protect against foreign objects with a diameter greater than 50mm falling into the equipment
Level 2: Can protect against foreign objects with a diameter greater than 12.5mm falling into the equipment
Level 3: Can protect against foreign objects with a diameter greater than 2.5mm falling into the equipment
Level 4: Can protect against foreign objects with a diameter greater than 1.00mm falling into the equipment
Level 5: It cannot completely prevent dust from entering, but the amount of dust
that enters must not affect the normal operation of the equipment and must not affect safety
Level 6: Completely dustproof



IP XX Reliability Test Electrical Appliances Water-Proof Prevent Intrusion Of Foreign Objects ETL/UL/TUV/MET 0

IEC/EN60529 waterproofing is divided into 9 levels (level 0 ~ level 8), waterproof level (e.g. IPX4-waterproof level 4):
Level 0: Completely waterproof and unprotected
Level 1: Water dripping from vertical directions should have no harmful effects
Level 2: When each vertical surface of the enclosure is tilted within 15°, vertical dripping water should have no harmful effects
Level 3: Water spraying within 60° of each vertical plane, no harmful effects
Level 4: Splashing water from all directions on the enclosure has no harmful effects
Level 5: Spraying water from all directions on the enclosure has no harmful effects
Level 6: Strong spraying of water from all directions on the enclosure has no harmful effects
Level 7: After being immersed in water at a specified pressure for a specified period of time, the amount of water entering the housing will not reach a harmful level.
Level 8: According to the conditions agreed between the manufacturer and the user (which should be more stringent than Level 7), the amount of water entering the shell after continuous diving will not reach a harmful level.



IP XX Reliability Test Electrical Appliances Water-Proof Prevent Intrusion Of Foreign Objects ETL/UL/TUV/MET 1

项目 UL cTUVus ETL
发证资格 美国NRTL(国家认可实验室)和加拿大标准局SCC
认可机构
认证市场 北美(美国及加拿大)
颁证及测 UL美华试验室检测 LCS测试 LCS测试
试机构 并出具结案信 TUV发证 ITS发证
申请时间 5-12周 3-4周 3-4周
参考
申请费用 相比三者比较贵 费用比较优惠 费用比较优惠
优势 美国本土机构,认可度最高 国际认证机构, 美国本土机构,认可度高
美加地区老牌认证机构 权威而不昂贵,
  同样得到美国NRTL的认可
劣势 因为是老牌机构,测试, 北美市场品牌知名度 在北美市场知名度
厂检及档案费最高,周期较长. 稍低于UL 稍微低于UL
